Six Channel 10 MHz Frequency Reference – OCXO based – NR3626-O


Six Channel OCXO Based 10 MHz Frequency Reference

Six Channel Low Phase Noise Reference Operates from-60 to +60 Vdc in Three Ranges or an AC Adapter


The NR3626 is a high performance 10 MHz frequency reference driven by a low noise SC cut, OCXO. 10 MHz outputs are 13 dBm. Optionally the unit can generate a synthesized PPS. The unit may be locked to an external PPS or 10 MHz reference. The unit may also be used as a six channel clean-up oscillator by locking to a external 10 MHz source that has been degraded. Outputs will be synchronized to the external source but phase noise will be dominated by the internal OCXO.

  • Low phase noise OCXO.
  • 6 channels 10 MHz channels also available 50 MHz
  • Low close-in phase noise.
  • Hold-over stability of 5 ppb/day, 50ppb/year.
  • Operates from DC power in three ranges +- (10 to 18, 18 to 36, 36 to 65) VDC or an AC adapter.
  • Indicators and signals provide unit self-test and channel fault status.
  • RS232 port provides BITE and channel status.

Wide input power range (-60 to +60 VDC) in three ranges

Brand : Novus          SKU :NR3626-O



Additional information

Data Sheet
